| Automatic locking screw machine SF-7024-2Z (Magnetic suction type) mechanical parameters |
1. Product scope of application: |
Applicable to: toys, small home appliances, electronic products, instrumentation, lighting, electronics, plastics, alloys, communication equipment, audio and other lock screw technology. |
|
|
|
|
|
|
|
|
|
2. Features: |
*Long-term magnetic suction screw structure, which can realize the locking function of the deep hole/bevel screw/meson screw of the product lock screw position |
*Dual-mode alternately locks two screws of different specifications at the same time (or operates separately) to replace the product to achieve high-efficiency work mode |
*Support leak lock/sliding tooth/floating tooth alarm function |
*Support the adjustment function |
*Support automatic induction start operation function |
*Support servo electric batch speed and torque independent adjustment function |
*Support manual drag adjustment to lock screw point adjustment function |
*The vertical belt seat does not need to add another work surface, and the working position can be adjusted flexibly. |
|
|
|
|
|
|
|
|
|
3. Technical parameters: |
| Locking screw range | X240*Y1/700*135mm X240*Y2/700*Z135mm(X*Y*Z/X*Y*Z) |
| Screwing time | 1.0~1.5Second/grain |
| Repeatability | +/-0.03mm |
| Program recording mode | 15 groups, 99POINTS per group |
| Electric batch method | Precision Servo Motor (Mitsubishi/Delta) |
| Feeding method | Turntable screw feeding method (own brand) |
| Control System | MCU + touch screen control system |
| Motor system | Precision stepping (closed loop) motor (domestic brand) |
| Transfer method | Synchronous belt/precision linear guide (Taiwan Shangyin) |
| Input power | 220V/50HZ |
| Working air source | 0.4~0.6MPA |
| Edit mode | Hand drag & teaching |
| Working temperature | 5~40 degrees |
| Working environment humidity | 20-90% |
| Applicable screw specifications | Cross recessed (flat head/round head/meson head) screws (except stainless steel) |
| Applicable lock screw size | M1.5~M4 (the screw length does not exceed 16MM) can be customized if it exceeds the range |
| Mechanical dimensions | 1090*810*1750mm(L*M*H) |
| Machine weight | 120KG |
